Electric Start Soundproof 50hz Single Phase Quanchai Diesel Generator 8kw
Engine :
Mechanical / Electric governing starting method
Nature / Turbocharged after water cooled intaking Method.
Closed water cooled system
Electric Starting
Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
Fuel injection pump
Low Consumption
Alternator :
Brand : Stamford or Leroysomer or our BOSS series brushless
Rated output : 12 - 184kW
Rated voltage : 400 / 230V, 380 / 220, 220 / 110, etc
Rated Frequency : 50 / 60Hz
Voltage regulation : AVR automatic
1.0% voltage regulation (max.) in static conditions
Protection class : IP 22 or IP23
H class insulation
| Genset Model | BS-QC10 | |
| Rated Output (KW/KVA) | 8KW/10KVA | |
| Max Output (KW/KVA) | 8.8KW/11KVA | |
| Phase | 3 | |
| Power Factor (cos Ø) | 0.8 | |
| Frequency | 50HZ/1500RPM | |
| Rated Voltage (V) | 400V | |
| Rated Current (A) | 14.4A | |
| Silent Genset Dimensions (MM)--N.W(KGS) | 1800*900*1000--640KGS | |
| Engine | Model | QC385D | |
| Type | 4-cycle, direct injection, In line, Water cooling | |
| Cylinder Numbers | 3-cylinder | |
| Rated Power (KW/KVA) | 10KW | |
| Air intake type | Natural Intake | |
| Combustion Chamber Type | Direct Injection | |
| Displacement(L) | 1.532 | |
| Compression Ratio | 18:1 | |
| Firing order | 1-3-2 | |
| Starting Type | Electric starting | |
| Alternator Assy | 14V×500W | |
| Starting motor | 12V×3kW | |
| Bore×Stroke (MM×MM) | 85x90 | |
| Intake Air flow | 65 kg/h |
| Exhaust Air flow | 68 kg/h |
| Fuel System | Fuel injection | Direct Injection |
| Governor | mechanical |
| Fuel consumption (kg/L) | 25% Load: 2.74 50% Load: 2.01 75% Load: 1.63 100% Load: 1.14 |
| Lube System | Oil Capacity | 4L |
| Max oil temperature | 115℃ |
| Oil Pressure (Kpa) | 100-650 |
| Cooling system | Cooling method | Water cooling |
| Water pump flow rate | 80L/min |
| Coolant Capacity | 3.15L |
| Max. Water Temperature | 95℃ |
| Thermostat Temperature | 70℃/82℃ |
| Alternator | Type | Copy Stamford-BS164B |
| Rated Output (KW/KVA) | 8.8KW/11KVA |
| Max Output (KW/KVA) | 9.7KW/12KVA |
| Power Factor (cos Ø) | 0.8 |
| Excitation Mode | single-bearing with SAE ,Brushless synchronous ,Three harmonic exciting |
| AVR Model | SX460 |
| Insulation Class | H CLASS |
| IP Level (PROTECTION) | IP23 |
Quanchai Engine :
Quanchai Generator sets seriers diesel engine has always been an excellent seriers of diesel quality,
the use of direct injection combustion chanber,easy to start,low fuel consumption,economy,compact structure,
light weight,easy to install layout.With strong motivation,small vibration,low noise,the performance advantage
of low transfer rate.The key components are optimized for high-speed automotive diesel engine parts and
components,so that diesel has a good reliability.Dynamic interface is in line with the SAE standard,having a
good market interchangeability and versatility.Electronic governor of selective installation makes revolving
speed much stable.
Q : What certificates do you have ?
A : We have CE , ISO. And we can apply for specific certificate for different country such as SONCAP
for Nigeria , CIQ for Egypt , SASO for Saudi Arabia , etc
Q : Does your generator have global warranty ?
A : Yes . Global warranty service is available depending on the engines and alternators you choose .
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T in advance, the rest payment before shipment. Or irrevocable L/C.
Q: What is your lead time?
A: About 30 days after receiving deposit or original L/C.But if your order with some special design,
then the delivery time is longer.
